Refine MaxSurgery III Piezo Ultrasonic Bone Cutting System with Light

MaxSurgery III Piezo Ultrasonic Bone-Cutting System — Illuminated

Piezo bone-surgery unit for minimally invasive osteotomy with micron-level tip vibration and selective cutting that spares soft tissue.

Smallest surgical cut about 3.5 mm × 0.5 mm for a smaller field and faster healing. High-intensity focused ultrasound affects bone of a certain hardness only — vessels and nerves are spared; bleeding control helps keep the wound smaller and more precise.

Technical specifications

• Model: MaxSurgery III
• Dimensions: 290 × 270 × 125 mm
• Main unit weight: 3 kg
• Power input: 100–240 V AC, 50/60 Hz
• Main unit input: 120 VA
• Frequency: 26±3 kHz
• Water flow: 30–125 ml/min
• Working modes: B, P, E, C
• Control: touch control

Why piezo

• Small incisions and faster healing
• Micron vibration without air stream — lower emphysema risk
• Reduced nerve injury and other complications
• Sterile saline irrigation helps limit infection risk
• Lower aerosol production reduces cross-infection risk

Applications

• Alveolar surgery: impacted tooth extraction, alveolar contouring
• Implant surgery: sinus lift, bone splitting, autogenous bone prep
• Periodontal surgery: crown lengthening, root modification
• Endodontic surgery: apicoectomy, apical curettage
• Orthodontic and maxillofacial surgery: cysts, orthopedic/plastic procedures
