Refine MaxCure 3 Polymerization Beam Filling Device

Product overview

MaxCure 3 dental LED curing light for rapid hardening of light-sensitive resins in clinical settings (trained dental professionals only).

Curing modes

• FULL — general use
• PULSE — gentler curing to help reduce composite shrinkage stress
• RAMP — gradual rise in the first 0–5 s for heat-sensitive patients

Technical data

• Light guide: FO, 8 mm diameter
• Wavelength: 430–480 nm
• Full: 1,200 mW/cm² ±10% — 5/10/15/20 s
• Pulse: 0–1,200 mW/cm² ±10% — 5/10/15/20 s
• Ramp: 0–1,200 mW/cm² for first 5 s, then 1,200 mW/cm² ±10% — 5/10/15/20 s
• Battery: 800 mA; input 100–240 VAC 50/60 Hz; output 5 V DC/1 A
• Operating: 5–40 °C; RH 30–75%; 70–106 kPa

Package contents

• 1× curing unit, 1× adapter, 1× light shield, 1× optical probe, 1× user manual
